1708072008
Identifies the Molex NeoScale High-Speed Mezzanine Connector series. Specifies a NeoScale High-Speed Mezzanine Plug with 2.80mm pitch, 6x12 configuration, 72 Triads-100 Ohm (216 Circuits), and 12.00mm connector height.
Part number dissection
—
170807Identifies the Molex NeoScale High-Speed Mezzanine Connector series.
2008Specifies a NeoScale High-Speed Mezzanine Plug with 2.80mm pitch, 6x12 configuration, 72 Triads-100 Ohm (216 Circuits), and 12.00mm connector height.
Specifications
Base codeIdentifies the Molex NeoScale High-Speed Mezzanine Connector series.
Finish / variantSpecifies a NeoScale High-Speed Mezzanine Plug with 2.80mm pitch, 6x12 configuration, 72 Triads-100 Ohm (216 Circuits), and 12.00mm connector height.
Connector TypeArray, Male Pins
Number of Positions72
Pitch0.110" (2.80mm)
Number of Rows6
Mounting TypeSurface Mount
FeaturesBoard Guide
Contact FinishGold
Contact Finish Thickness30.0µin (0.76µm)
Mated Stacking Heights-
Height Above Board0.634" (16.10mm)
